Model number DW80B7071US/AA
Design
Handle Type Bar Control Type Hidden Touch General Feature Rotary Exterior Color Fingerprint Resistant Stainless Steel Place Setting 15 Display Color White Display Position Top Performance
Dry System Smart Dry Programs Auto Yes Delicate Yes Pre Blast Yes
Option
Delay Start Yes (1-24H) Hi-Temp Wash Yes Control Lock Yes
Cutlery Basket
Cutlery Basket Yes Cutlery Tray (3rd Rack) Yes
General Feature
Handle Type Bar
Power/Ratings
Electrical (Voltz/Hertz/Amps) 120/60/15 Heater Watts 1100 Circulation Motor 60~100 Drain Pump Yes Drain Pump Watts 35
Awards and Certificates
ENERGY STAR® Most Efficient Yes
Key Features
3rd Rack Yes Express 60 Yes Adjustable Rack Yes
Wi-Fi Connectivity Yes Smart AutoRelease™ Door Drying Yes StormWash+™ Cleaning Yes
Standard Features
Cancel & Drain Button Yes Start & Pause Button Yes Rack Coating Material Nylon Digital Leak Sensor Yes Wash Arm Upper/Mid/Low Kickplate Color Black Silence Rating 42 dBA Control Type Top Control Handle Type Bar Handle Download Cycles Yes Ventilation Drying System (Fan Assisted) Yes Self-Cleaning Filter System Yes Whisper Quiet Yes Optimal Cycle Detection Yes
Wash Options
Half Load Yes Sanitize (Anti-bacterial-NSF) Yes Smart Control (Wi-Fi) Yes
Racks/Interior
Upper Rack Adjustable Height One-touch Upper Rack Basket Handle Plastic Upper Rack Adjustable Tines 1 Upper Rack Cup Shelf Foldable (Plastic) Lower Rack Basket Handle Yes Lower Rack Maximum Vertical Loading Dimension 13 1/2" Lower Rack Fold Down Tines Yes Lower Rack 2 Piece Silverware Basket Yes Lower Rack Adjustable Tines Yes Lower Rack Removable Tines Yes Upper Rack Soft Rail (Glide Rail) Yes
Energy & Performance
Energy Usage (kWh/year) 239 Water Consumption (gallons/cycle)3.2 ENERGY STAR® Certified Yes
Cut-Out Dimensions
Width - Min 24" Height - Min 34.1" Depth - Min 24" Height - Max 35.3"
Wash System
Number of Programs 7 Normal Cycle Yes Heavy Cycle Yes Express 60 Yes
General Information
Tub Material STSS Heater Position Hidden
Weights & Dimensions
Product Weight 91.5 lbs. Width 23 7/8" Product Dimensions 24.8" D x 33.9" H x 23 7/8" W Counter Depth 23 7/8" Product Height w/ Legs Extended 35" Height (decimal) 33.875 - 35 Width (decimal) 23.875 Depth (decimal) 25
